Industrial Low Series Flange Type Linear Rail Block
Optimize your automation and precision machinery with our Industrial Low Series Flange Type Linear Rail Block. Engineered for applications where space is limited but performance is non-negotiable, this block is the cornerstone of reliable linear motion. For scenarios demanding exceptional accuracy, our High Precision Low Series Flange Linear Motion Block delivers superior smoothness and positional repeatability. When structural integrity and simplified mounting are key, the Integrated Flange Low Series Linear Rail Guide Block offers a robust, one-piece design. In highly compact equipment, our Small Size Low Series Flange Type Linear Guide Unit provides full functionality with a minimal footprint. For operations involving significant forces, the Heavy Load Low Series Flange Type Linear Rail Block ensures unwavering stability and long service life. Each variant is built to reduce friction, minimize maintenance, and enhance the overall efficiency of your systems.
The Industrial Low Series Flange Type Linear Rail Block is meticulously constructed from high-grade steel, undergoing rigorous heat treatment and precision grinding to achieve optimal hardness and geometric accuracy. Its integrated flange design allows for direct and secure mounting to machine beds or moving platforms, simplifying installation and saving valuable design space. The block incorporates a optimized ball recirculation system within a compact housing, ensuring smooth, quiet, and consistent travel along the matched rail. Pre-loaded ball bearings eliminate internal clearance, providing high rigidity and immediate response to movement commands, which is critical for high-speed and high-acceleration applications. Standard versions include highly effective seals and scrapers to prevent contamination from dust, chips, and fluids, significantly extending the component's operational lifespan even in challenging industrial environments. This design philosophy makes the Industrial Low Series Flange Type Linear Rail Block a versatile and dependable choice for a wide range of sectors including semiconductor manufacturing, medical device assembly, packaging machinery, and precision measuring equipment.
Key Specifications & Dimensions
- Series Designation: Low Profile / Low Series
- Mounting Style: Flange Type (Integrated Flange)
- Preload Grades: Normal (C0), Light (C1), Medium (C2)
- Accuracy Class: Normal (N), High (H), Precision (P), Super Precision (SP)
- Ball Circuit: 4-Row, Double Arc Gothic Arch Design
- Sealing System: Multi-lip End Seals & Scraper Seals
- Lubrication: Standard Grease Fitting & Optional Oil Lines
| Model | H (Height mm) | W (Width mm) | L (Length mm) | Bolt Hole Spacing (mm) | Bolt Size | Dynamic Load (C) kN | Static Load (C0) kN |
|---|---|---|---|---|---|---|---|
| LW15-FL | 15 | 34 | 45 | 40 | M5 | 9.8 | 14.2 |
| LW20-FL | 20 | 45 | 58 | 50 | M6 | 16.5 | 25.0 |
| LW25-FL | 25 | 52 | 72 | 60 | M6 | 22.3 | 36.8 |
| LW30-FL | 30 | 64 | 90 | 70 | M8 | 33.1 | 54.9 |
Performance Characteristics
- High Rigidity & Stability: The flanged structure and four-point contact design provide excellent resistance to moment loads (pitch, yaw, roll) and overturning forces.
- Smooth Motion & Low Noise: Precision-ground raceways and optimized ball size ensure consistent rolling contact with minimal vibration and acoustic emission.
- Long Service Life: Advanced sealing technology effectively retains lubrication and excludes abrasive contaminants, dramatically reducing wear.
- Easy Installation & Maintenance: The integrated flange facilitates alignment and mounting. Standard grease fittings allow for easy re-lubrication.
- Interchangeability: Manufactured to international dimensional standards, ensuring compatibility with common rail profiles for easy replacement or upgrade.
